Programming the Outputs

• An output is required for every controlled floor, and for every elevator car.
• In our scenario, we need a total of 13 outputs:
  • 4 outputs for each of the Office elevators
  • 5 outputs for the Service elevator
• The output is required to establish and break contact between the elevator car panel and the lift controller
• We need to configure an output for each button that can be pressed to select a floor
