Invert Follow and Test Output

Inverted Follow and Test Output: This mode can be used when the state of the area/area group is required to do the opposite of the checked output.

• If the output turns on, the controlled area/area group disarms
• If the output turns off, the controlled area/area group arms

The Inverted Follow and Test Output mode performs the same function as the Follow and Test Output mode however the area state is inverted (NOT).

In between state changes, the controlled area/area group state is continually tested at approximately 30 second intervals. When the controlled area/area group's state is changed by an external operation, the programmable function restores it within 30 seconds.
