Fail Secure Destination Reporting Wiring

Fail secure destination reporting requires an additional wire from the contacts of the relay to the input terminal on the PRT-ISO16-DIN.

A button voltage common wire is also required from the elevator control system.

Note: It is important that the active input to the PRT-ISO16-DIN is linked from the side of the relay that is not switched.
