Follow Logic NAND

The Follow Logic NAND (NOT AND) programmable function performs a logical NAND operation on output 1 and 2 with the controlled output changing state according to the result.

The controlled output turns on if neither, or only one of the checked outputs is on. The Controlled output turns off if both checked outputs are on.
